Cisco SF302-08MPP

Характеристики

Rack-Mount 23 in. (58.4 cm) EIA

Included

Jumbo Frame Support

9 KB

Routing Protocol

Static IPv4 routing

Minimum Storage Temperature

-4 F

Depth

6.7 inches

MTBF

899,905 hours (@40C)

Cables Included

1x Serial Cable

Capacity

4K Active VLANs

Height

1.45 inches

Maximum Operating Temperature

104 F

MAC Address Table Size

16k entries

Localization

Chinese (simplified), English, German, French, Italian, Spanish, Japanese

Width

11 inches

Enclosure Type

Desktop, rack-mountable - 1U

Maxiumum Storage Temperature

158 F

Ports

8-port 10/100 + 2 x combo Gigabit SFP

Device Type

Switch - 8 ports - L3 - managed

Humidity Operating Range

10-90% (non-condensing)

Weight

2.6 lbs

Minimum Operating Temperature

32 F

Interfaces

8 x 10Base-T/100Base-TX - RJ-45 - PoE; 1 x console - 9 pin D-Sub (DB-9) - management; 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 / SFP (combo)

Humidity Storage Range

10-90% (non-condensing)

Flash Memory

16 MB

Voltage Required

AC 120/230 V ( 50/60 Hz )

Performance

Switching capacity: 5.6 Gbps; Forwarding performance (64-byte packet size): 4.17 Mpps

Power Device

Power adapter - external

Power Over Ethernet (PoE)

POE and POE+

Status Indicators

Link activity, port transmission speed, system

Ram

128 MB

Authentication Method

Secure Shell (SSH), RADIUS, TACACS+
